40G QSFP+ Transceiver
Product Details
  • Vendor Name
    Fiberland
    Form Type
    QSFP+
  • Data Rate
    40Gbps
    Wavelength
    850/1310NM
  • Reach
    100M~80KM
    Optical Interface
    MPO/LC
  • Media Type
    MM/SM
    DDM Support
    YES
  • Commercial Temp.
    0~70℃
    Industrial Temp.
    -40~85℃
  • Compatible Brands
    Cisco,HP,Huawei,etc...
    Certificates
    CE,FCC,ROHS,REACH
  • HS Code
    8517706000
    Warranty
    3 Years
Multi vendor compatible QSFP+ transceivers are available in Fiberland.Currently we are able to offer 40G QSFP+ SR4,QSFP+LR4,QSFP+ ER4 30KM,QSFP+ ER4 40KM.QSFP+ BIDI,QSFP+ CSR4,QSFP+ DAC,QSFP+ AOC,QSFP+ breakout AOC(Active optical cable and 40G QSFP+ breakout DAC (direct attached cable).

Fiberland 40G QSFP+ transcievers designed to operate over single-mode fiber system using 4X10 CWDM channel in 850nm & 1310nm. The module converts 4 inputs channel of 10Gb/s electrical data to 4 CWDM optical signals, and multiplexes them into a single channel for 40Gb/s optical transmission. Reversely, on the receiver side, the module optically de-multiplexes a 40Gb/s input into 4 CWDM channels signals, and converts them to 4 channel output electrical data.

The central wavelengths of the 4 CWDM channels are 1271, 1291, 1311 and 1331 nm. It contains a duplex LC connector for the optical interface and a 38-pin connector for the electrical interface. Single-mode fiber (SMF) is applied in this module. This product converts the 4-channel 10Gb/s electrical input data into CWDM optical signals (light), by a 4-wavelength Distributed Feedback Laser (DFB) array. The 4 wavelengths are multiplexed into a single 40Gb/s data, propagating out of the transmitter module via the SMF. The receiver module accepts the 40Gb/s optical signals input, and de-multiplexes it into 4 CWDM 10Gb/s channels. Each wavelength light is collected by a discrete photo diode, and then outputted as electric data after amplified by a TIA.

The product is designed with form factor, optical/electrical connection and digital diagnostic interface according to the QSFP+ Multi-Source Agreement (MSA) and compliant to 40G QSFP+ LR4 of IEEE 802.3ba.

The description of QSFP+ LR4 is 40G QSFP+ with wavelength of 1310NM ,transmit distance is 10km. 40G QSFP+ transceivers are widely used in the application of data center,big Data Signal Transmission and etc.

Fiberland’s 40G QSFP+ transceivers are 100% compatible with over 200 brand equipment in the market such as Cisco,HP,HUAWEI,ARISTA and etc.Currently fiberland is able to offer 40G QSFP+ SR4,QSFP+ LR4,QSFP+ ER4 LITE 30KM,QSFP+ ER4 40KM,QSFP+ PSM4 2KM,QSFP+ PSM4 10KM,QSFP+ SR BD and etc. Most commonly used cisco 40G QSFP+ TRANSCIEVER part number is QSFP-40G-SR-BD,QSFP-40G-CSR4,QSFP-40G-SR4,QSFP-40G-LR4,QSFP-40G-ER4, QSFP-40G-PSM4 ,QSFP-40G-ZR4,and etc.
Quality Commitment

Fiberland Technology Co.,Ltd 's aim is to provide you high quality products.We are doing products aging for standard 8 hours and 100% funtion tested before shipping. Besides,Fiberland products are with quality system verifications,such as CE,FCC,ROHS as well as REACH.We record the ID (Serial Number) of products with our ERP system in order to track our products easily.


More Options
  • Part No.
    Product Type
    Rate
    Media Type
    Wavelength
    Reach
    Connector
    Commercial Temp.
    Industrial Temp.
    Optional
  • FLD-QSFP+SR4
    QSFP+
    40G
    MM
    850MN
    150M
    MPO
    0~70℃
    -40~85℃
    DDM
  • FLD-QSFP+LR4-2
    QSFP+
    40G
    SM
    1310NM
    2KM
    LC
    0~70℃
    -40~85℃
    DDM
  • FLD-QSFP+LR4-10
    QSFP+
    40G
    SM
    1310NM
    10KM
    LC
    0~70℃
    -40~85℃
    DDM
  • FLD-QSFP+ER4-30
    QSFP+
    40G
    SM
    1310NM
    30KM
    LC
    0~70℃
    -40~85℃
    DDM
  • FLD-QSFP+ER4-40
    QSFP+
    40G
    SM
    1310NM
    40KM
    LC
    0~70℃
    -40~85℃
    DDM
  • FLD-QSFP+CSR4
    QSFP+
    40G
    MM
    850NM
    300M
    MPO
    0~70℃
    -40~85℃
    DDM
  • FLD-QSFP+SRBD
    QSFP+
    40G
    MM
    850/900NM
    100M
    LC
    0~70℃
    -40~85℃
    DDM
  • FLD-QSFP+PSM4
    QSFP+
    40G
    SM
    1310NM
    10KM
    MPO
    0~70℃
    -40~85℃
    DDM
  • FLD-QSFP+LX4
    QSFP+
    40G
    MM/SM
    1310NM
    150M/2KM
    LC
    0~70℃
    -40~85℃
    DDM
  • FLD-QSFP+IR4
    QSFP+
    40G
    SM
    1310NM
    2KM
    LC
    0~70℃
    -40~85℃
    DDM
  • FLD-QSFP+ZR4-L
    QSFP+
    40G
    SM
    1310NM
    60KM
    LC
    0~70℃
    -40~85℃
    DDM
  • FLD-QSFP+ZR4-80
    QSFP+
    40G
    SM
    1310NM
    80KM
    LC
    0~70℃
    -40~85℃
    DDM
