10G optical network module connectivity solutions
2017-08-29
In 10G networks, engineers are often confused about the choice of optical fiber or copper / optical cable. Today, Fiberland will analyze three 10G network communication solutions for everyone to reference.
Solution 1: 10G SFP+ module + patch cord + 10G SFP+ module
Solution 2: 10G SFP+ to 10G SFP+ DAC Cable
In the data center, copper cable is usually used in connecting the server and storage area network (SAN). Most is direct attach copper cable, and the passive copper cable is the most using.
For the cheaper price and higher transmission speed of passive copper cable, it becomes the best service solution of realizing the short distance transmission.
Solution 3: 10G SFP+ to 10G SFP+ AOC Cable
Active Optical Cable = two optical transceivers + optical patch cord
Customers may be tangled in which product is suitable for his project, please look at below picture!
Everything has two sides, both advantages and disadvantages. Although the solutions 2 and 3 are relatively cost-effective compared with solutions 1, there are certain risks.
If one side of 10G DAC or 10G AOC was broken, then it will be unworkable. For solutions 1, if some part was broken, replace the broken part can also continue to use.
XFP module,XFP transceiver,bidi sfp,SFP+ module,SFP+ transceiver Which is good? First choice Fiberland！Thanks for your concern, to learn more about Fiberland, please enter Fiberland website: http://www.fiberlandtec.com/
