Fiber Optic Tool - Industry's smallest package 10G XFP module
2017-10-07
Optical module is an important device in optical fiber communication. It is composed of three parts: optical receiving function, light transmitting function and digital diagnosis function. It realizes the function of optical signal and electrical signal conversion signal. In the data communication, transmission network, Storage network, cloud computing and other fields have a wide range of applications.
As the XFP module uses limited space, the control component volume is the key, XJX for your selection of XFP transceiver with 5 × 5mm industry's smallest package, low power consumption, low jitter and other excellent performance, small size, more effective Cost savings!
[Preferred]
Small and low cost 10G XFP optical module preferred device program
• EFM8LB series 8-bit MCUs with digital diagnostics, up to 72MHz, 14-bit precision ADCs, 4 12-bit precision DACs and hardware high-speed I2C peripherals (up to 3.4Mbps), internal FLASH can achieve EEPROM function, can save external EEPROM, further reduce the product size, small package (QFN24 3 * 3mm);
• The SI5040 is used to implement the CDR function. The chip integrates LA (limiting amplifier), low power consumption (only 575mW) and small package (5 * 5mm LGA).
As the XFP module uses limited space, the control component volume is the key, XJX for your selection of XFP transceiver with 5 × 5mm industry's smallest package, low power consumption, low jitter and other excellent performance, small size, more effective Cost savings!
[Preferred]
Small and low cost 10G XFP optical module preferred device program
• EFM8LB series 8-bit MCUs with digital diagnostics, up to 72MHz, 14-bit precision ADCs, 4 12-bit precision DACs and hardware high-speed I2C peripherals (up to 3.4Mbps), internal FLASH can achieve EEPROM function, can save external EEPROM, further reduce the product size, small package (QFN24 3 * 3mm);
• The SI5040 is used to implement the CDR function. The chip integrates LA (limiting amplifier), low power consumption (only 575mW) and small package (5 * 5mm LGA).
