Some Useful Informations Of The Optical Module Interface
2017-09-01
In order to make the new partner learning the optical module interface easily, so summarize some useful information as below :The Interface Type of XFP Module: Dual fiber interfaces, Single fiber interfaces and RJ-45 interfaces.
1.Dual-fiber interfaces : The common are dual-fiber SC and dual-fiber LC
2.Single fiber interfaces: Single fiber SC and single fiber LC
3.RJ-45 interfaces : The transmission medium is a coaxial cable (twisted-pair)
The SC interface module connect the SC patch cord , the LC interface module connect the LC patch cord.
The optical fiber including some type:
1. SM OS2 9/125um
2. MM OM1 62.5/125um
3. MM OM2 50/125um
4. MM OM3 50/125um
5. MM OM4 50/125um
The Copper-T SFP connect the cat5 or Cat6 UTP/FTP cable.
Every point connect by the fiber and patch cable , finally it makes us enjoy the internet!
XFP module,XFP transceiver,bidi sfp,SFP+ module,SFP+ transceiver Which is good? First choice Fiberland！Thanks for your concern, to learn more about Fiberland, please enter Fiberland website: http://www.fiberlandtec.com/
